• Low profile plastic chamber, also suitable for patients with thick subcutaneous fat layer
    • Light weight and cost-effective
    • Titanium internal chamber avoid damages induced by needle tip and avoids interactions between plastic and drugs
    • Large self-sealing septum facilitates location during skin palpation and reduces risks of punture concentration
    • transparent and radiopaque elastomeric connector allows rapid, safe and reversible connection of the catheter

    Features

    Chamber
    Material Titanium + Polysulfone
    Shape and dimensions: circular –  base diameter  27 mm
    Height: 10.6 mm
    Weight: 5.9 g
    Internal Volume : 0.36 ml

    Catheter with rounded tip, marked with a dot every centimeter and a number every 5 centimetres.

    Septum
    Material Silicone
    Diameter available for punctures: 13 mm
    Maximum number of punctures: 2000 with 22G Huber needle
    1000 with 19G Huber  needle
    Code
    Product
    configuration
    PLP
    Material
    ID
    (mm)
    OD
    (mm)
    Size
    (Fr)
    Length
    (mm)
    Introducer
    Size
    (Fr)
    Gravity
    Flow
    (ml/min)
    19G
    201.22.12.21
    All-in-One
    silicone
    1.00
    2.10
    6,5
    780
    6.5
    12
    201.22.12.31
    All-in-One
    silicone
    1.50
    2.70
    8
    780
    9
    18
    201.22.12.41
    All-in-One
    PUR
    1.10
    1.70
    5
    780
    5
    13
    201.22.12.20
    All-in-One
    PUR
    1.30
    2.00
    6
    780
    6.5
    21
    201.22.12.33
    All-in-One
    PUR
    1.60
    2.70
    8
    780
    9
    24
    201.22.17.21
    All-in-One*
    silicone
    1.00
    2.10
    6,5
    780
    6.5
    12
    201.22.17.31
    All-in-One*
    silicone
    1.50
    2.70
    8
    780
    9
    18
    201.22.17.41
    All-in-One*
    PUR
    1.10
    1.70
    5
    780
    5
    13
    201.22.17.20
    All-in-One*
    PUR
    1.30
    2.00
    6
    780
    6.5
    21
    201.22.17.33
    All-in-One*
    PUR
    1.60
    2.70
    8
    780
    9
    24
    All-in-One Kit contents
    Chamber
    Catheter
    Connector
    Straight Huber needle 22G x 1″
    Luer Connector
    Peel-away Introducer-dilator
    18G Introiducer needle
    0.89 mm J-tip guidewire
    Stainless steel tunneler

    All-in-One*: this configuration includes also a 10ml syringe, a blunt tip needle, a vein lifter, 20G Huber needle with extension

    Venous introduction set

    Code Colour Code
    201.51.10.21 introduction set 6.5 FR
    10
    201.51.10.31 introduction set 9 FR
    10
    201.51.10.41 introduction set 5 FR
    10

  • INFUSION SYSTEMS

    Venous catheters ad
    Peripheral Access

    Healthmid

    HEALTHMID® is a peripheral venous catheter for short or medium term use. It allows the intravenous administration of fluids and drugs compatible with such peripheral positioning.
    It can also be used for high pressure contrast media infusions. It is not a Central Catheter so the insertion procedure is easier and faster than that of a PICC as it does not require verification of tip positioning. Not being a central catheter, it is not suitable for the infusion of drugs and substances that exclusively require this type of access such as substances with osmolarity > 600 mOsm / l, pH < 5 or pH > 9, and irritating drugs.

    Code Lumen Ø (Fr) Material Length (mm) Max Flow Rate (ml/s) Reverse Taper Markings
    HEALTHMID® WITH REVERSE TAPERING LENGTH 25 CM
    201.62.10.13 single 3 PUR 250 2 Yes Yes
    201.62.10.14 single 4 PUR 250 5 Yes Yes
    201.62.10.15 single 5 PUR 250 7 Yes Yes
    201.62.10.24 double 4 PUR 250 2 Yes Yes
    201.62.10.25 double 5 PUR 250 5 Yes Yes
    HEALTHMID® NO REVERSE TAPERING LENGTH 25 CM
    201.67.12.13 single 3 PUR 250 2 No Yes
    201.67.12.14 single 4 PUR 250 5 No Yes
    201.67.12.15 single 5 PUR 250 7 No Yes
    201.67.12.24 double 4 PUR 250 2 No Yes
    201.67.12.25 double 5 PUR 250 5 No Yes
    HEALTHMID® NO REVERSE TAPERING W/STYLET LENGTH 25 CM
    201.67.22.13 single 3 PUR 250 2 No Yes
    201.67.12.14 single 4 PUR 250 5 No Yes
    201.67.12.15 single 5 PUR 250 7 No Yes
    201.67.12.24 double 4 PUR 250 2 No Yes
    201.67.12.25 double 5 PUR 250 5 No Yes
     HEALTHMID® NO REVERSE TAPERING W/STYLET  LENGTH 20 CM
    201.67.42.13 single 3 PUR 250 2 No Yes
    201.67.42.14 single 4 PUR 250 5 No Yes
    201.67.42.15 single 5 PUR 250 7 No Yes
    201.67.42.24 double 4 PUR 250 2 No Yes
    201.67.42.25 double 5 PUR 250 5 No Yes
    HEALTHMID® NO REVERSE TAPERING LENGTH 20 CM
    201.67.32.13 single 3 PUR 200 2 No Yes
    201.67.32.14 single 4 PUR 200 5 No Yes
    201.67.32.15 single 5 PUR 200 7 No Yes
    201.67.32.24 souble 4 PUR 200 2 No Yes
    201.67.32.25 double 5 PUR 200 5 No Yes

    INSTRUCTIONS FOR USE

    PACKAGING

    Box: 5 units
    Unit: a rigid blister sealed with Tyvek foil (first sterile barrier) contained within a medical paper pouch (second sterile barrier).

  • GAVeCeLT 2021 recommendations for the indication, implantation and management of venous access devices.
    Curated by Mauro Pittiruti and Giancarlo Scoppettuolo
    Raccomandazioni GAVeCeLT 2021

  • ACCESSOIRES POLYSWAB SWAB CAPS
    Disinfectant caps for catheter maintenance

    14280-14282

    Disinfectant cap

    • Provides instant and efficient active disinfection
    • Compatible with all needle-free access and luer systems
    • Eliminates personal compliance variations of the scrub the hub disinfection method and saves scrubbing time.
    • Ergonomic design for easy use
    • PVC-free, lactive-free, DEHP-free
    • Sterile range
    • Available in single pack and multipack
    • Available options:
      – 70% isopropyl alcohol
      -70% isopropyl alcohol + 2% chlorhexidine

    Code

    Product description

    90309

    disinfectant cap

  • HUBER NEEDLES

    14280-14282

    • Compatible with totally implantable vascular access devices
    • Also available with safety mechanism (Power Injectable)
    • PVC DEHP free extension line
    • Non coring needle
    • Latex free
    • Optional Y site and Needle Free Connector
    • Needle length: 15mm, 19mm, 25mm, 32mm, 38mm

    Code

    Item description

    201.11.59.11

    201.11.59.12

    201.11.59.13

    201.11.59.14

    201.11.59.21

    201.11.59.22

    Huber needle STD 19Ga 19mm with extension

    Huber needle STD 19Ga 25mm with extension

    Huber needle STD 19Ga 30mm with extension

    Huber needle STD 19Ga 37mm with extension

    Huber needle STD 20Ga 19mm with extension

    Huber needle STD 20Ga 25mm with extension

  • Catheter Mount

    Catheter Mount

    20180

    • Suitable for connection between endotracheal tube and breathing circuits
    • Provided with 22 mm standard female connector compatible with all breathing & ventilator circuit
    • An elbow port is provided for easy suctioning without causing disturbance to breathing circuits
    • I.D. 15 mm / O.D. 22 mm
  • HME Filter

    HME Filter

    20424

    • Filter Particles
    • Moisture return: 32mg H2 O/L
    • Flow rate: 30L minute at pressure 0.2Mpa
    • Filter Efficiency: Greater than 95%
    • Minimum tidal Volume: 150ml

  • Endotracheal Tube (Cuffed)

    20150-20916

    Autofusion Set


    Endotracheal Tube (Plain)

    20932-20939

    Novofusion Set

    • Provided with soft cuff based on high volume and low pressure at the distal end
    • Non-return valve with pilot cuff for easy assessment of the pressure in the main cuff
    • Made of special thermo sensitive material readily conforming to body curvatures at body temperature

    Endotracheal tube sizes (I.D. of the tube in mm):

    Cuffed – – 3.5 4 4.5 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10
    Plain 2 2.5 3 3.5 4 4.5 5 5.5 – – – – – – –

    Common Features

    • Proximal end fitted with standard 15 mm connector
    • Radiopaque line on the tube to facilitate easy location of tube
    • Murphy eye at distal end for atraumatic intubation and extubation
  • Vial Access Spike
    Autofusion Set

    Polyspike

    Vial Access Spike

    13490-13496

    •  Vented spike for withdrawing fluids from vials or semi-rigid containers
    •  Reduces contamination through safety snap cap
    •  Available with green, blue & red color caps
    •  PVC free, DEHP free, Latex Free
    Polyspike Variants Fluid Filter Air Filter Nature of Use
    Polyspike R 5µ 0.1µ Chemotherapeutic Drugs
    Polyspike B 5µ 0.1µ Normal Drugs
    Polyspike G NA 0.1µ Normal Drugs

  • Technology Quick Flashback (Adva) I.V.

    Adva Quick Flashback Technology Needle Catheter

    quick flashback that instantly confirms the success of venipuncture
    needle technology improves first-time puncture success
    instant confirmation of blood flow through the catheter body increases the likelihood of successful vein access

    POLYTROL – IV Set with Micro Drip & Flow Regulator

    14280-14282

    • Flow regulator integrated into I.V. infusion set for precise flow control
    • Flow rate 5ml/hr to 250ml/hr
    • Aproximately 60 drops/ml
    • Also available with standard drip chamber (20 drops/ml)
    • Latex free

    the special Priming filter ensures the filling of the infusion line (auto priming) and keeps the line closed until it is connected to the patient
    contributes to the reduction of hospital infections by reducing liquids subject to potential colonization
    avoids the spillage of infusional liquids on the hands, floor or patient bed and avoids the waste of medication

    Features:

    • suitable for gravity infusions only
    • transparent and soft drip chamber;
    • 15 micron fluid filter in the drip chamber;
    • the soft and anti-throttling PVC hose guarantees a uniform flow;
    • standard length of the tube: 150 cm;
    • tube diameter: inner 3mm / outer 4.1mm.

    Lenght
    (cm)

    Y-site

    Clamp

    Luer Lock
    rotating

    Filter
    priming

    Code

    150 – DEHP Free

    N

    Orange

    Y

    Y

    14260

    180 – DEHP Free

    Y – Latex Free

    White

    Y

    Y

    14261

    180 – DEHP Free

    N

    Orange

    N

    N

    14263
