• High profile
  • Chamber designed to be used at high flows for injections of contrast media
  • The large surface of the septum facilitates localization during skin palpation and reduces the risk of close punctures
  • Transparent and radiopaque elastomeric connector: fast, safe and reversible connection of the catheter

Caratteristiche

Chamber
Material Titanio
Shape and size: Wedge- diam. base. 22 mm x 26 mm
Height: 13 mm
Wheight: 12 g
Internal Volume: 0.82 ml

Catheter with rounded tip, dot marking every centimeter and number every 5 centimeters.

Septum
Material Silicone
Diameter available for punctures: 13 mm
Maximum number of stings: 2000 with Huber’s needle from 22GA
1000 with Huber’s needle from 19GA

Max Flow Rate: 5ml / s with Max pressure 300PSI, Max Viscosity 12cP

Code
Item
description
POWER TI
Height
mm
Weight
g
Material
ID
mm
OD
mm
Size
Fr
Lenght
mm
Introducer
Dimension
Fr
Flow
mL/min
22GA
Flow
mL/min
19GA
201.23.12.30
All-in-One
13
12
silicone
1.30
2.70
8
600
9
7
21
201.23.12.20
All-in-One
13
12
PUR
1.35
2.00
6
600
6.5
8
22
201.23.12.33
All-in-One
13
12
PUR
1.60
2.70
8
600
9
8
24
201.23.10.30
Standard
13
12
silicone
1.30
2.70
8
600
NA
7
21
201.23.10.20
Standard
13
12
PUR
1.35
2.00
6
600
NA
8
22
201.23.10.33
Standard
13
12
PUR
1.60
2.70
8
600
NA
8
24
All-in-One Kit Contents
Chamber
Catheter
Connector
Huber’s needle 22GA x 25.4 mm
Luer Connector
Introducer-dilator peel-away
Introducer needle from da 18GA
Guide at “J” from 0.89 mm
Tunneler in stainless steel
Standard Kit Contents
Chamber
Catheter
Connector
Huber’s needle 22GA x 25.4 mm
Luer

Venous introduction set

Code Colour Code
201.51.10.21 Introduction Set 6.5 FR
10
201.51.10.31 Introduction Set 9 FR
10
  • Introducer-dilator peel-away
  • Introductor needle da 18 GA
  • Guide at “J” from 0.89 mm
  • Tunneling in stainless steel
