PORT BRACHIALE


Following the introduction of the ultrasound-guided venipuncture technique of the deep veins of the arm, it is now possible to combine the advantages of a fully implantable subcutaneous chamber (PORT) with the catheter introduction and placement technique typical of PICCs.
The catheter is introduced and positioned as for the PICC implantation technique: ultrasound-guided venipuncture, micro introduction set, ECG control of the tip.
The catheter is then connected to a small PORT chamber, inserted in a subcutaneous pocket of the middle third of the arm.

Main indications:

  • chemotherapeutic treatments
  • anatomical difficulties with the implantation of traditional ports (prostheses, burns, tracheostomies, etc.)
  • aesthetic needs

PICC-PORT main advantages:

  • absence of the exit-site
  • reduced risk of infections
  • less maintenance
  • reduced visibility of the chamber
  • less invasiveness and perceptibility for the patient

Features

Chamber
Material: Titanio
Shape and size: Wedge – base 21 mm x 16 mm
Height: 8,6 mm
Weight: 6 g
Interior Volume: 0,2 ml
Septum
Material: Silicone

Available diameter for punctures:
9 mm
Maximum number of stings: 1500 with Huber’s needle of 22GA

Portata Max: 2 ml/s con Max pressione 300PSI, Viscosità Max 12cP


Catheter with rounded tip, dot marking every centimeter and number every 5 centimeters

Code
Item
description
minMAX
Height
mm
Weight
g
Material
ID
mm
OD
mm
Size
Fr
Lenght
mm
Introductor
Size
Fr
Flow
ml/min
22GA
Flow
ml/min
19GA
201.16.17.55
All-in-one
8.6
6
PUR
1.10
1.70
5
780
5
8
1


Kit Contents

Chamber
Catheter
Connector
Huber’s needle 22GA x 25.4 mm
Luer’s connector
Straight tip Nitinol guide
Self-centered needle from 21 GA
Dilator / Introducer
Tunneler in stainless steel
